Product Introduction
16×1.5 Air Compressor Breathing Nozzle
M16×1.5 Threaded Vent Plug for Crankcase Pressure Balance
A Small Vent Part with a Clear Fitment Check
This breathing nozzle is used at a compatible air-compressor crankcase vent or maintenance port. It gives the housing a defined path for pressure balance instead of leaving the port open to the workshop environment. The same connection may appear near an oil-fill opening, but the port function should be confirmed before replacing an existing part.
The fitment is specific: an M16×1.5 external thread, 10.0mm effective thread length and S17 hex for tightening. The body is 28.0mm high. The supplied image shows an orange ribbed housing and a black sealing ring; these visible details are kept separate from the specification-table material description.


Technical Profiles & Materials
M16×1.5 External Thread
The external thread is M16×1.5: 16.0mm nominal major diameter and 1.5mm pitch. A compatible port should provide the required thread engagement for the listed 10.0mm effective length.
Metal Housing and S17 Installation Section
The specification identifies an industrial-strength metal body with anti-corrosion treatment. The 28.0mm overall height and S17 / 17mm hex section determine the space needed above the crankcase cover and around the installation tool.
Vent Opening and Sealing Point
The listed vent opening is Φ3.5mm. The black ring visible at the base of the orange housing sits at the mating surface, so the port face, thread and seal should be inspected together rather than judged from the nozzle alone.
Technical Specifications
| ITEM | DETAILS |
| Type | 16×1.5 Air Compressor Breathing Nozzle |
| Application | Air-compressor crankcase ventilation, pneumatic equipment, workshop maintenance and industrial machinery |
| Code | 1401102 |
| Material | Industrial-strength metal body with anti-corrosion treatment; visible orange ribbed housing and black sealing ring |
| Details explanation | M16×1.5 external metric thread; 16.0mm major diameter; 1.5mm pitch; 10.0mm effective thread length; 28.0mm overall height; S17 hex; Φ3.5mm vent hole; threaded installation |
| Brand Name | SeaSummer |
| Operating Temp | -20°C to +120°C |
| Delivery Time | 30 Days |
| Packaging | Cardboard packaging |
Products Application

Crankcase Vent Installation
Use the nozzle at a compatible crankcase vent port when the assembly requires controlled housing ventilation and pressure balance. Check the thread depth and leave enough room for an S17 / 17mm wrench.

Vent and Oil-Fill Port Arrangement
On some compressor covers, the vent point is located beside an oil-fill plug. The two parts serve different purposes, so confirm the port function and the equipment drawing before treating the nozzle as a replacement.

Compressor Maintenance and Replacement
During service, inspect the existing thread, sealing face, vent opening and surrounding clearance. This information is more useful for replacement decisions than the outside colour alone.
Quality and Craftsmanship Details



Products Package

About Us
As a premier garden machinery parts supplier, Jiaxing Norsun Trading Co., Ltd. bridges global distributors with over 100 vetted China manufacturers. We streamline your B2B supply chain through strict quality control, flexible production, and factory-direct wholesale pricing. Partner with us for reliable, high-volume sourcing of precision-engineered outdoor power equipment components.
Trusted Partnership Power
YOUR PROFESSIONAL ONE-STOP SOURCE
FOR 10000+ OUALITY PARTS
Verified Factory Excellence
BACKED BY 200+ TRUSTED FACTORY PARTNERS
Production process








Quality control




Expo experience

Customer Reviews

FAQ
Q: What thread does this breathing nozzle use?
A:M16×1.5 external metric thread, with a 16.0mm major diameter and 1.5mm pitch.
Q: What space is needed for installation?
A: Allow for the 28.0mm height, 10.0mm effective thread length and S17 / 17mm tool access. The mating port must provide compatible thread engagement.
Q: Is this the same as an oil-fill plug?
A:Not necessarily. This part is described as a breathing and pressure-balance component. Confirm the port function and equipment drawing before replacing an oil-fill or other service plug.
Q: What should be checked before ordering?
A: Confirm the M16×1.5 port, thread depth, vent function, sealing face, S17 clearance, pressure, temperature, quantity and destination.
