Agriculture Sprayer Flexible Joint

Agriculture Sprayer Flexible Joint

SKU / Model Identifier: 0403118 (OEM Cross Reference: RE307561)
Equipment Scope: Agricultural Boom Sprayers, Self-Propelled Plant Protection Rigs, Combine Harvesters, Forage Harvesters
Driveline Location: Tractor PTO Output Shaft to Implement Input Driveline / High-Pressure Sprayer Plunger Pump
Key Dimensions & Metallurgy: Overall Length: 95.25 mm (3.75 in) × Overall Span: 50.8 mm (2.0 in) | Unit Net Weight: 0.86 kg | Case-Hardened Alloy Steel
Commercial Terms: Brand: SeaSummer | Delivery Time: 30 Days | Packaging: Cardboard packaging
Send Inquiry
Add To Inquiry
Description

Jiaxing Norsun Trading Co., Ltd. is one of the leading manufacturers and suppliers of agriculture sprayer flexible joint in China. With abundant experience, we are committed to providing high quality customized products with low price. Welcome to wholesale bulk CE approved products in stock here and get quotation from our factory.



Product Overview & Operating Details

Agricultural Sprayer & Farm Machinery PTO Driveline Universal Joint Cross Assembly (RE307561)

Heavy-Duty Hardened Alloy Steel U-Joint Cross with Precision Needle Roller Bearings & Corrosion-Protected Bearing Caps for High-Pressure Sprayers, Combines & Harvesters



product-1024-1024

Mechanical Role & Power Transmission Dynamics

In commercial agricultural crop protection and harvesting, power is transmitted from the tractor Power Take-Off (PTO) output shaft to high-pressure sprayer plunger pumps and implement gearboxes through multi-joint cardan driveshafts. As tractors traverse uneven field terrain, ridge contours, and headland turns, the driveshaft experiences continuous angular deflection and rotational shock loads.

Without high-precision universal joint cross assemblies, severe angular misalignment produces high-frequency rotational vibration, localized torsional stress, and premature bearing spalling. Furthermore, direct exposure to corrosive chemical sprays, liquid fertilizer mist, and field mud accelerates needle bearing wear and leads to joint seizure.

This heavy-duty universal joint cross assembly is forged from case-hardened alloy steel and precision-ground to provide exceptional core toughness and surface wear resistance. High-capacity needle roller bearing assemblies distribute radial driveline loads evenly across all four cross journals. Corrosion-protected bearing cap surfaces and a center grease zerk allow regular purging of contaminants with EP-2 lithium grease, dampening driveline vibration and protecting expensive PTO splines and pump bearings.







Technical Specifications





Parameter Specification
Product Description Agricultural Sprayer & Implement Driveline Universal Joint Cross
SKU / Part Code 0403118
OEM Cross Reference RE307561 (John Deere / Commercial Agricultural Equipment Fitment)
Brand Identifier SeaSummer
Applicable Machinery Agricultural Sprayers, Plant Protection Equipment, Combines, Forage Harvesters
Driveline Position Tractor PTO Shaft to Implement Driveline & Sprayer Pump Input Shaft
Overall Length (Cap Span) 95.25 mm (3.75 inch)
Overall Height / Width 50.8 mm (2.0 inch)
Unit Net Weight 0.86 kg
Cross Body Metallurgy High-Strength Case-Hardened Alloy Steel (Precision Heat-Treated)
Internal Bearing Type Heavy-Duty Precision Needle Roller Bearings
Corrosion Protection Chemically Protected Bearing Cap & Journal Surfaces (Agrichemical Resistant)
Lubrication Interface Central High-Pressure Grease Nipple (Grease Zerk for EP-2 Lithium Grease)
Operational Function Transmits Continuous PTO Torque, Absorbs Angular Misalignment & Shock Loads
Delivery Time 30 Days
Packaging Cardboard packaging



Products Application





product-880-752

Pre-Assembly Dimensional Verification

Inspect the cross journals and needle bearing cups for surface finish and needle retention. Measure the overall bearing cap-to-cap span with digital vernier calipers to confirm 95.25 mm (3.75 in) length and 50.8 mm (2.0 in) width. Ensure all bearing cups contain their full complement of needle rollers and that internal grease seals are intact.

product-880-752

Assembly Sequence

Disassemble the worn universal joint from the driveshaft yoke using a mechanical press or dedicated U-joint puller. Avoid heavy hammer blows to prevent distorting the yoke ears.

Clean and deburr the internal yoke bore and snap ring grooves thoroughly; apply a light film of clean oil or grease.

Position the new universal joint cross body inside the yoke ears, ensuring the center grease zerk is oriented for easy field access.

Press the bearing cups into the yoke bores over the cross journals, taking care not to dislodge or skew any internal needle rollers.

Install new retaining snap rings / circlips into the yoke grooves on both sides. Confirm that each circlip is fully seated around its entire circumference.

Connect a manual or pneumatic grease gun to the center zerk fitting and inject EP-2 extreme-pressure lithium grease until fresh grease purges past all four bearing seals.

Reconnect the driveshaft to the tractor PTO and implement, confirming proper phasing of the driveline yokes.

product-880-752

Field Maintenance & Lubrication Protocol

Greasing Interval: During peak spraying and harvest seasons, lubricate the universal joint cross every 8 to 10 operating hours to maintain grease barrier protection and purge dirt and spray chemicals.

Yoke Alignment: Always ensure the driveshaft yokes at both ends are aligned in the same plane (proper phasing) to prevent rotational pulsation and cyclic driveline vibration.

Quality and Craftsmanship Details



product-1500-1500







Products Package





product-1500-1500



About Us





Jiaxing Norsun Trading Co., Ltd.

As an established supplier of outdoor power equipment and pneumatic components, Jiaxing Norsun Trading Co., Ltd. delivers streamlined B2B sourcing for global distributors. Backed by 200+ audited manufacturers in China, we ensure factory-direct wholesale pricing, strict incoming and outgoing inspection, and steady volume supply.

One-Stop Sourcing Hub

YOUR PROFESSIONAL ONE-STOP SOURCE
FOR 10000+ OUALITY PARTS

Direct Factory Network

200+ TRUSTED MANUFACTURING PARTNERS ACROSS CHINA

Production process


product-496-372
Injection MoldingPlastic & Rubber Parts
product-496-372
CNC Lathe TurningHigh-Precision OD/ID
product-496-372
CNC Machining CenterMulti-Axis Milling
-5
Precision TappingCalibrated Thread Pitch
product-496-372
Clean Assembly LineSemi-Automated Line
product-496-372
100% QC InspectionOptical & Pressure Test
product-496-372
Protective PackagingCardboard & Rust-Proof
-6
Warehouse & LogisticsFast Dispatch & Storage

Quality Assurance & Traceability: Every pneumatic component is manufactured under strict ISO quality management standards-from raw material inspection and CNC machining to thread gauge verification and 100% pressure leak testing



Expo experience





product-1500-2000



Customer Reviews





product-1500-2000





Practical Questions & Ordering





Q:Is this universal joint cross compatible with John Deere part number RE307561?

A: Yes. This assembly matches John Deere OEM specification RE307561 with standard 95.25 mm (3.75 in) × 50.8 mm (2.0 in) dimensions and is engineered for direct replacement on agricultural boom sprayers, combines, and forage harvesters.

Q: How does this cross assembly withstand agrichemical corrosion?

A:The bearing cups and exposed journal surfaces undergo specialized anti-corrosion surface treatments that resist acidic and alkaline fertilizer mist, chemical pesticide spray residues, and outdoor washdown moisture.

Q: Can this joint handle high angular deflection during tight headland turns?

A:Yes. The heavy-duty needle roller bearings and high-strength alloy steel cross body are designed to accommodate dynamic angular displacement while transmitting continuous PTO torque without binding.



Q:What are the wholesale export packing details and standard lead time?

A:Each universal joint cross is packaged in a corrosion-inhibiting protective wrap and individual carton, then packed into master export Cardboard packaging. Standard production delivery time is 30 Days.
