GT3.5- FE05 Lawn Mower PTO Clutch Ogura

GT3.5- FE05 Lawn Mower PTO Clutch Ogura

SKU:0650-Og-GT35FE05
Application:lawn tractor
Material: steel
Operating Temp:Up to 370°F
Packaging:Cardboard packaging
Delivery Time:30 Days
Send Inquiry
Add To Inquiry
Description
Brand Name SeaSummer SKU 0650-Og-GT35FE05
ID 1.125" Pulley 6.1"
Rotation CCW Belt 1/2" or 5/8" Belt
Bolt Torque 272 ft. lbs. Maximum Engine RPM 3,600 RPM
Voltage Insulation 1000V Temperature Up to 370°F (188°C)
Net Weight 5kg Carton Dimensions 68 x 46 x 26 cm
MOQ 100pcs Customized Services OEM
Delivery Time 30 days, volume-dependent Packaging Cardboard packaging



Products Description

product-700-700

PTO Clutch For Ogura - GT3.5-FE05

This electric PTO clutch is a direct replacement built to match Ogura model GT3.5-FE05 specifications, engineered for equipment applications that depend on precise, repeatable blade or implement engagement. The unit combines a high-output electromagnetic coil with a friction assembly tuned to reproduce the original's engagement curve - firm pickup, smooth holding, clean release - so the machine behaves exactly as designed. Dimensional control is held against the GT3.5-FE05 reference: mounting pattern, shaft fit and electrical interface all align with the original, making the exchange a direct, bolt-for-bolt operation with no adaptation work. Construction emphasizes endurance under real conditions: heat-tolerant materials protect the coil and friction surfaces through sustained operation, while sealed internals resist the dust and moisture that shorten the life of lesser units. Every batch is tested for coil integrity and engagement consistency before dispatch, and stock is maintained to serve both urgent single-unit repairs and scheduled volume programs - original-spec performance at a price the aftermarket can live with.

Vehicle Compatibility

Replacement Numbers

Ogura 526105
Ogura GT3.5-FE05
Ogura GT35FE05
Xtreme X0650

Products Advantages

Why Choose Our Electric PTO Clutch over Generic Replacements?
The Industry Problem: Most aftermarket clutches burn out prematurely due to low-grade copper windings (Class B/F insulation) and unsealed bearings that trap turf debris.
product-700-700
Coil overheated and burned out
product-700-700
Bearings prone to seizing or bursting
product-700-700
Severe vibration & damages the engine
product-700-700
Wire harness breakage poor waterproofing
Our Solution:
product-555-320
01

Brand-Channel Pricing Penalizes Every Replacement

When a machine is down, the last thing you want is a parts quote that feels like a penalty - but that is exactly what the original-brand channel delivers on the GT3.5-FE05. Our replacement is built to the same spec and engagement behavior at an aftermarket price, so the repair stays economical, the machine gets back to work faster, and the savings stay on your side of the ledger.

02

Spec-Matched Means No Surprises at Install

clutch that only "kind of" matches the reference creates problems at the worst moment - during installation, when the machine is already apart. This unit is manufactured against the GT3.5-FE05 dimensions and verified across its mounting surfaces, so the procedure runs straight through: out with the old, in with the new, harness connected, done. No improvisation, no return labels.

product-555-320
product-555-320
03

Engagement Consistency Is the Product

In applications where the clutch cycles frequently, inconsistency is costly - a hard grab here, a lazy pickup there, and the driven equipment never performs the same twice. Our coil and friction pack are designed for stable, repeatable engagement across temperature swings and thousands of cycles, so the equipment's behavior stays predictable from the first run of the day to the last.

04

Downtime Is Priced in Hours, Not Parts

Every day a unit sits waiting for parts is a day of lost output that no invoice can recover. We keep the GT3.5-FE05 in working stock and back it with continuous production, covering emergency single orders and planned bulk programs alike - with functional testing completed on every batch before it ships, so the part that arrives is the part that finishes the job.

product-555-320


Quality and Craftsmanship Details

product-1920-1920

product-1920-1920

Products Package



seasummer packing



About Us



Jiaxing Norsun Trading Co., Ltd.

As a premier garden machinery parts supplier, Jiaxing Norsun Trading Co., Ltd. bridges global distributors with over 100 vetted China manufacturers. We streamline your B2B supply chain through strict quality control, flexible production, and factory-direct wholesale pricing. Partner with us for reliable, high-volume sourcing of precision-engineered outdoor power equipment components.

Trusted Partnership Power

YOUR PROFESSIONAL ONE-STOP SOURCE
FOR 10000+ OUALITY PARTS

Verified Factory Excellence

BACKED BY 200+ TRUSTED FACTORY PARTNERS

Production process

-1
Assembling
-2
CNC Machining Center
-8
CNC Lathe
-5
Tapping Machine
-3
Tapping Machine
-7
Injection Molding Machine
-4
Inspecting
-6
Warehousing



Quality control

-1
-3
-4
-2

Expo experience



seasummer expo experience



Customer Reviews



seasummer reviews



FAQ

Q: How do I select the correct electric PTO clutch for my specific mower model?

A:To guarantee a 100% exact fit, you need to verify four critical mechanical dimensions:1. Shaft Bore Size: Common sizes are 1" (25.4 mm) or 1-1/8" (28.6 mm).2. Pulley Outer Diameter (OD) & Belt Width: Matches your deck's V-belt size (e.g., 1/2" or 5/8").3. Rotation Direction: Clockwise (CW) or Counter-Clockwise (CCW) when viewing from the pulley end.4. OEM Cross-Reference: Compare with original numbers (Warner, Ogura, John Deere, etc.).If you provide us with your engine model or original part number, our engineering team will cross-check our database and provide a 3D fitment drawing for confirmation.

Q: What measures are taken to prevent the coil from burning out during heavy-duty operation?

A: Our electric PTO clutches are built with Class H insulated copper wire, rated for temperatures up to 180°C (356°F). Combined with dual-sealed C3 high-speed bearings and dynamic balance calibration, our design reduces friction-induced heat, significantly lowering the risk of thermal coil failure under prolonged high-load conditions.

Q: What is your quality inspection protocol before shipment?

A:Every single clutch (100% full inspection, not random sampling) passes through our 4-step automated testing rig before packaging:

1. Coil Resistance & Amperage Test: Verifies electrical integrity.2. Static Torque Capacity Test: Ensures proper torque engagement under load.3. Air Gap Precision Check: Factory preset to optimal clearance (0.012" - 0.020") for immediate response.4. Dynamic Balance & Noise Level Test: Ensures vibration-free operation.

Q: Do you offer custom OEM/ODM development for specialized lawn equipment manufacturers?

A: Yes. We regularly partner with OEM machine builders and private-label brand owners. Our customization capabilities include:Custom Wiring Harnesses: Wire gauge, sleeve protection (corrugated/braided), and waterproof connector types (Deutsch, Molex, Amphenol).Custom Pulley Configurations: Single/double groove, specific ODs, and anti-corrosion plating.Branding & Packaging: Laser-etched logos/part numbers on the steel body, custom color box packaging, and barcoded master cartons.
