TL43/CG430/40-5/TL52/CG520/44-5 Bracket

TL43/CG430/40-5/TL52/CG520/44-5 Bracket

SKU / Model: 0202118 | Engine Base Mounting Series
Material: Stamped cold-rolled steel plate with black protective finish
Mounting Holes: 4-leg bolt eyelets with central slotted alignment slots
Fastener Compatibility: Designed for standard M5 / M6 machine bolts
Engine Platforms: 43cc (1E40F-5) and 52cc (1E44F-5) 2-stroke small engines
Delivery Time: 30 Days
Packaging: Cardboard packaging
Send Inquiry
Add To Inquiry
Description

Jiaxing Norsun Trading Co., Ltd. is one of the leading manufacturers and suppliers of tl43/cg430/40-5/tl52/cg520/44-5 bracket in China. With abundant experience, we are committed to providing high quality customized products with low price. Welcome to wholesale bulk CE approved products in stock here and get quotation from our factory.



Product Overview & Operating Details

Brush Cutter Engine Mounting Bracket

Stamped Steel Support Plate with Black Finish for 43cc and 52cc 2-Stroke Trimmers



product-1024-1024

Mechanical Construction & Frame Fit

Stamped Steel Base Plate

This bracket connects the bottom crankcase of a 2-stroke engine to the main handle and shaft frame on compatible grass trimmers. Formed from cold-rolled steel sheet, the plate maintains fixed spacing between the engine base and the machine frame during regular field cutting.

Hole Layout and Leg Profile

The bracket has four formed support legs with pre-drilled eyelets, along with two slotted holes on the center section. The slotted holes allow slight lateral adjustment during assembly so mounting bolts line up cleanly with threaded holes on standard 40-5 and 44-5 crankcase castings.

Surface Finish

A black paint coating is applied over the steel body to provide basic surface protection against surface rust from outdoor moisture and dirt contact during yard maintenance.







Technical Specifications





Parameter Specification
Product 2-Stroke Brush Cutter Engine Mounting Bracket
SKU 0202118
Brand SeaSummer
Material Stamped Cold-Rolled Steel
Finish Black Paint Coating
Hole Pattern 4-Leg Corner Holes with Dual Center Adjustment Slots
Mounting Hardware Fits standard M5 / M6 Fasteners
Engine Fit 43cc (40 mm bore) and 52cc (44 mm bore) 2-Stroke Engines
Engine Series 1E40F-5, 1E40F-5A, 1E44F-2A, 1E44F-5
Compatible Trimmers TL43, CG430, 40-5, TL52, CG520, 44-5, BC430, BC520
Delivery Time 30 Days
Packaging Cardboard packaging






Products Application





product-1024-1024

Hole Spacing and Slot Alignment

Sample checks on the production line measure center-to-center hole spacing across the four mounting legs to ensure consistency with standard crankcase casting patterns.

product-1024-1024

Mounting onto Engine Base

Position the bracket against the crankcase mounting pads, start all bolts by hand through the eyelets and center slots to verify thread engagement, and then torque each fastener down in an alternating pattern.

product-1024-1024

Equipment Operation

With the engine securely fastened to the chassis, the trimmer can be used for typical grass cutting, weed clearance, and edging tasks.
