Product Parameters
| Specification Item | Description |
|---|---|
| Compatible Models | FS230 / FS235 / FR230 / FR235 |
| OEM Part Number Reference | 4151-400-1300 / 0000-400-1306 |
| Coil Type | Solid-state ignition module (no breaker points) |
| Spark Plug Wire | Integrated (attached to coil body) |
| Wire/Boot Type | Includes terminal and spark plug boot |
| Mounting Type | Screw/bolt attachment to engine housing |
| Air Gap Setting | Approx. 0.25–0.30 mm (0.010–0.012 inches) |
| Package Weight | Approx. 0.2 kg (0.44 lbs) |
Product Description
The FS230 Ignition Coil is a direct replacement ignition component for Stihl FS230, FS235, FR230, and FR235 brush cutters. This solid-state ignition module generates the high-voltage spark required at the spark plug to ignite the fuel-air mixture in the engine cylinder . Designed as a maintenance-free component, the ignition coil operates automatically as part of the engine's normal function once correctly installed .
Product Details
1. Direct Drop-In Replacement
Manufactured to OEM specifications for FS230, FS235, FR230, and FR235 models, ensuring precise fitment without modification. The integrated spark plug wire and boot simplify installation .
2. Solid-State Ignition Design
Modern electronic ignition module eliminates breaker points and condenser, providing maintenance-free operation, consistent spark output, and improved reliability compared to older ignition systems .
3. Wide Compatibility
This ignition coil configuration (referencing OEM #0000-400-1306) is compatible with multiple Stihl models including FS160, FS180, FS220, FS280, FS290, and MS series chainsaws, making it a versatile replacement part .
Products Package
About Us
Production
Quality control
FAQ
Q1: How do I know if my FS230 ignition coil needs replacement?
A: Common symptoms include no spark or intermittent spark, engine hard starting or failure to start, misfiring or running rough, and engine losing power or stalling when hot . Perform a spark test by grounding the spark plug against the cylinder and pulling the starter cord-a weak, yellow, or no spark indicates coil failure .
Q2: What is the correct air gap for installation?
A: The air gap between the ignition coil and the flywheel magnets should be set to approximately 0.25–0.30 mm (0.010–0.012 inches) . The easiest method is to loosen the coil mounting screws, insert a standard business card (approximately 0.3mm thickness) between the coil and flywheel, push the coil against the flywheel, then tighten the screws and remove the card .
